FD1608Y
8 PON PORTS GPON OLT

Name: FD1608Y
Brand: Shenzhen C-Data Technology Co., Ltd.

FD1608Y GPON OLT is a field-type central office equipment. The product adopts cast aluminum shell, which has good heat dissipation and shielding effect. The equipment is flexible to use and easy to deploy, meeting the requirements of equipment performance in outdoor environment.

The device provides 2 uplink GE ports, 2 uplink SFP ports, 2*10GE uplink ports and 8 GPON ports, 1 in-band management port, 1 out-band management port, and supports dual power supply configuration.

The maximum split ratio of each GPON optical port is 128, and the system can support up to 1024 ONUs. The product is suitable for FTTH access, video surveillance network, enterprise LAN, Internet of Things and other network applications of operator networks, and has a high cost performance.

 Download  Inquiry

Technical Specifications

ITEM		FD1608Y
Management Rack	Type	Field type slave equipment,Cast aluminum housing
Uplink Port		2* 10/100/1000M auto-negotiation Ethernet ports 2 SFP interfaces 2 SFP+ interfaces
PON Port	Quantity	8
	Physical interface	SFP slot
	Interface type	GPON: ITU-TG.984.2 Class B+/Class C+
	Max splitting ratio	GPON: 1:128
Management Port		1 100/1000BASE-Tx out-band Ethernet port 1 CONSOLE local management port
PON Port attribute	Transmission distance	20KM
	Port rate	GPON: Downstream: 2.5Gbps Upstream: 1.25Gbps
	Wavelength	Forwarding: 1490nm Receiving: 1310nm
	Interface type	SC/UPC
	Fiber type	9/125μm SMF (Single Mode Fiber)
	Light transmission power	Class B+ +1.5～+5dBm Class C+ +3～+7dBm
	Receiving sensitivity	Class B+ : -28dBm Class C+ : -30dBm
	Saturation power	Class B+ -8dBm Class C+ -12dBm
Network management method		Support CLI、SNMP、TELNET、SSH、WEB
Business capabilities		Support device log, device upgrade, device management, condition monitoring, configuration management, and user management. Layer 2 switching configuration management: Like port management, VLAN, RSTP, IGMP, ACL, QOS and so on. PON function configuration management: Like OLT authentication, DBA template, service template, line template and so on. Layer 3 function: support static routing, dhcp-relay and vlanif configuration
Backplane Bandwidth		78G
Size		385306.95180mm
Weight		12.6KG
Power supply	220VAC	AC: 100V～240V，50/60Hz
Working environment	Working temperature	-40~65℃
	Storage temperature	-40～85℃
	Relative humidity	5～90% (Non-condensing)
