FD624TS3-R850S
1*2.5G+3GE+2POTS+2WIFI6(AX3000)

Name: FD624TS3-R850S
Brand: Shenzhen C-Data Technology Co., Ltd.

FD624TS3-R850s is WiFi6 XGSPON VoIP Gateway ONT,it support 802.11a/b/g/n/ac/ax standards over 2.4GHz and 5GHz,max speed can up to 3000Mpbs.

FD624TS3-R850s have a high reliability and provide quality of service guarantee, easy management, flexible expansion and networking.

Technical Specifications

Hardware
User Port (LAN)		RJ-45 connector
		3* 10/ 100/ 1000Mbps and 1*2.5G adaptive Ethernet port (There is a 2.5G LAN port, which defaults to 2.5G. Compatible with GE/2.5G)
		Full/half duplex
		Auto MDI/ MDI-X
Indicators		PWR / PON / LOS / LAN1-4 / INT / TEL1-2 / WIFI / USB
PON Port	PON Mode	XGSPON：FSAN G.9807.1 standard

PON Rate	XGSPON：10Gbps/10Gbps downstream/upstream
Wavelength	Transmit: 1270nm	Receiver: 1577nm
Receiving sensitivity	XGSPON：-28dBm
Saturated power	XGSPON：-9dBm
Average sending	XGSPON：+4～+9dBm

WIFI
IEEE802.11b/g/n/ax(2.4G) IEEE802. 11a/n/ac/ax(5G)
2.4G: 40Mhz bandwidth maximum rate 574Mbps 5G：160Mhz bandwidth maximum rate 2402Mbps Total wireless rate is 3000Mbps
2.4G EIRP:22dBm / 5 G EIRP:21dBm

User Port(POTS)

RJ-11 connector

2*accounts

SIP protocol

TDMF

G711U/G711A/G729/G722 encoding and decoding
