The CS2160G series unmanaged switches are full Gigabits Ethernet switch designed for high forwarding network environment such as school, family, SMEs and mini monitoring. It has 16 10/100/1000Mbps adaptive Ethernet ports. All ports support wire-speed forwarding and the data rate is up to 1000Mbps. There is 4K lightning protection to ensure smooth and stable operation. Auto MDI/MDIX is also available. No configuration is required; it will instantly operate as soon as you power it up.
| Item | CS2160G |
| Specifications | 16*RJ45 |
| Ports | 16*10/100/1000M BASE-T RJ45 |
| Switching capability | 32Gbps |
| Packets switching capability | 23.8Mpps |
| Switching method | Storage forwarding |
| DIP | support VLAN 、Extend mode |
| LED light | PWR（Power indicator） Link（Network Link） LOOP（Loop alarm） 1000M |
| Enviroment parameters | Work temperature: -10 - to 55℃ Storage temperature: -40 - 70℃ Work humidity: 10% to 95% Storage humidity: 10% to 95% |
| MAC table size | 8K |
| Input Power | Input: 100-240V AC, 50/60Hz |
| Dimention（W*D*Hmm） | 270×180×45mm |
| Weight | N.W: 1Kg; G.W: 1.5Kg |
| Certification compliance | FCC CE ROHS |
| Installation | Rack/ Desktop |
